Description
Lilliput Q17 Overview
- 1Description
- 2Versatile Inputs/Loop Outputs
- 3Color Calibration
- 4Gamma Options
- 5Remote Control
- 6High Dynamic Range
- 7Display Functions
- 8Versatile Mounting
The Q17 17.3" 12G-SDI/HDMI HDR Monitor from Lilliput is a 1920 x 1080 resolution production monitor that supports up to UHD 4K input and loop output. Its display provides 1200:1 contrast, 300 cd/m2 brightness, and a wide 170 x 170° viewing angle. The integrated battery plate enables you to use longer-lasting Gold mount batteries when not working near an AC power source. The Q17 monitor features one HDMI 2.0, two 12G-SDI, and two 3G-SDI inputs and loop-through outputs. It also features 12G-SDI single-link, dual-link, and 3G-SDI quad-link options plus an expansion slot for an optional 12G SPF+ module.
Pro features that help you obtain optimal images include HDR and 3D LUT support, adjustable gamma, LAN and RS-422 remote control options, and an audio vector and level monitoring. Monitor display functions include a 16:9 aspect ratio, quad-view, false color, focus peaking, check field, image flip, image freeze, selectable markers, and color temperature functions. The Q17 monitor comes with multiple mounting options, a USB drive, an acrylic screen protector, and a carrying case.
Versatile Inputs/Loop Outputs
- 12G-SDI single/dual/quad link
- 3G-SDI
- HDMI 2.0
Color Calibration
Color Spaces
- SMPTE C
- Rec. 709
- EBU
Color Temperature
- 3200/5500/6500/7500/9300K
- Customizable settings
Gamma Options
- Gamma can be adjusted between 1.8 to 2.8 for better detail in dark areas
Remote Control
- LAN control
- RS-422 control
- Lissajous audio vector
- Audio levels
High Dynamic Range
- Selectable HDR offers greater detail in highlights and shadows
- Supports ST2084/ST2084 1000/HLG
Display Functions
- Quad-view
- False color
- Focus peaking
- Check field
- Image flip
- Image freeze
- Selectable markers
- Color temperature selection
Versatile Mounting
- Tabletop base
- Tilting bracket
- Carrying case
- Rack-mountable
In the Box
- Lilliput Q17 17.3" 12G-SDI/HDMI HDR Monitor (Gold Mount)
- 15 VDC Power Adapter with AC cord
- VESA Mount Plate
- Gold Mount Battery Plate
- Carrying Case
- 2 x Base Bracket
- Tilt Bracket
- USB Flash Drive
- Acrylic Screen Protector
- Limited 1-Year Warranty
- Description
- Versatile Inputs/Loop Outputs
- Color Calibration
- Gamma Options
- Remote Control
- High Dynamic Range
- Display Functions
- Versatile Mounting
Lilliput Q17 Specs
| Panel Type | IPS-Type LCD |
| Display Size | 17.3" / 43.9 cm |
| Resolution | 1920 x 1080 |
| Aspect Ratio | 16:9 |
| Viewing Angle | Horizontal: 170° Vertical: 170° |
| Touchscreen | No |
| Maximum Brightness | 300 cd/m2 |
| Contrast Ratio | 1200:1 |
| Pixels Per Inch (ppi) | 127 ppi |
| Color Gamut | 100% Rec. 709 100% SMPTE-C 100% EBU |
| Real-Time LUT Monitoring | SDR, HDR |
| Image Controls | Anamorphic De-Squeeze, Blue Only, Check Field, Color Temperature Selection, False Color, Focus Peaking, Histogram, Image Flip, Pixel-to-Pixel Zoom, RGB Parade, Screen Markers, Vectorscope, Waveform, Zebra |
| Video | 2 x BNC (12G-SDI) Input 2 x BNC (3G-SDI) Input 3 x HDMI Type A (HDMI 2.0) Input 2 x BNC (12G-SDI) Loop Output 2 x BNC (3G-SDI) Loop Output 1 x HDMI Type A (HDMI 2.0) Loop Output |
| Embedded Audio | SDI: 16-Channel HDMI: 8-Channel |
| Audio | 1 x 1/8" / 3.5 mm Headphone Output |
| Built-In Speaker | 2 |
| Power I/O | 1 x XLR 4-Pin (15 VDC) Input |
| Other I/O | 1 x GPI (RJ45) Input 1 x LAN () Input 1 x RS-422 (RJ45) Input 1 x RS-422 (RJ45) Output |
| Expansion Slots | 1 x SFP+ Slot |
| Media/Memory Card Slot | None |
| Wi-Fi | None |
| Video Format | SDI UHD 4K: 60/50/30/25/24 1080p: 60/50/30/25/24 1080PsF: 30/25/24 1080i: 60/50 720p: 60/50 HDMI UHD 4K: 60/50/30/25/24 1080p: 60/50/30/25/24 1080i: 60/50 720p: 60/50 |
| Gamma Curve | HDR-HLG, Sony S-Log, Sony S-Log 2, Sony S-Log 3 |
| DC Input Power | 12 to 24 VDC |
| Battery Type | 1 x Gold Mount |
| Power Consumption | 26.5 W |
| Mounting-Hole Pattern | 100 x 100 mm, 75 x 75 mm |
| Operating Temperature | 32 to 122°F / 0 to 50°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Dimensions | 17.1 x 10.4 x 2.1" / 434 x 263 x 54 mm |
| Weight | 7.1 lb / 3.2 kg |
| Package Weight | 20.45 lb |
| Box Dimensions (LxWxH) | 21.3 x 15.4 x 7.6" |
