Description
OWC Gemini External HDD Overview
- 1Description
- 2Ultra-Performance and Convenience for Production Workflows
- 3Put Ultra X2 to Work
- 4Ultra X2 Models
- 5Reclaim Your Desktop
- 6Stay Connected to Your Team and Media
- 7Gain an 8K Perspective
- 8Ready to Work Anywhere
- 9Innergize Your Workflow with Highest Performance and Reliability
- 10Work with Maximum Confidence and Reliability
- 11Easy RAID Management
- 12Professional Grade = Ready to Work
Designed to handle demanding photography, video, and editing tasks, including 8K and 6K multi-cam sequences using advances 10 and 12-bit codecs, high framerate footage, and ultra-high resolution raw images, the 16TB Gemini Ultra X2 Thunderbolt 3 RAID Array and Docking Station from OWC / Other World Computing lets users edit ultra-high resolution files on the fly, ingest several media cards in parallel, render dailies, and more. Compatible with Windows and Mac, the Gemini Ultra X2 connects to your host system using a 40 Gb/s Thunderbolt 3 port, while a second Thunderbolt 3 port may be used to create a daisy-chain with up to five additional devices, charge compatible devices with up to 27W of power, or connect one 8K/60 Hz or one 4K/120 Hz display. Other available ports include two USB-A 3.2 Gen 2 ports, a 2.5 Gigabit Ethernet port, a HDMI 2.1 port that supports 8K/120 Hz, and a UHS-II SD/SDHC/SDXC card reader.
The Gemini Ultra X2 has two drive bays that support both 2.5" and 3.5" SATA drives, 2.5" and 3.5" U.2 drives, and NVMe M.2 drives using a U.2 adapter. This model is configured with 2 x 7.68TB WD Ultrastar DC SN640 2.5" NVMe U.2 SSDs, for a total capacity of 16TB. The system comes preconfigured as software-controlled RAID 0, which provides enhanced performance with read speeds of up to 1446 MB/s and write speeds of up to 1350 MB/s. However, it may also be reconfigured as RAID 1, for 1:1 data redundancy, or JBOD, which lets you use each drive independently. Operations are kept cool using an aluminum enclosure with a 3000 rpm cooling fan.
Ultra-Performance and Convenience for Production Workflows
While the base model Gemini is great for everyday content creators, you are worlds beyond ordinary. Your workflow is at the extreme edge of resolutions, codecs, and framerates. OWC understand your need to push into an other world of capability, and pros like you are the reason they created the Gemini Ultra. Powered by 6 x 2TB Aura P13 Pro NVMe SSDs, you'll have the horsepower to handle the most demanding photography, video, and editing tasks you face. Edit ultra-high resolution files on the fly, ingest several media cards in parallel, render dailies without a hitch, and rip through 8K footage with transfer speeds of up to 2381 MB/s.
Beyond performance, with the Gemini Ultra's seven connectivity ports, you will experience an incredible level of versatility. Use your favorite accessories and charge small mobile devices via two USB-A 3.2 Gen 2 ports. Daisy chain up to five Thunderbolt devices so that you can create additional backups. Offload media cards faster and easier with the frontside UHS-II slot or external card readers via Thunderbolt or USB-C. Transfer files and work up to 2.5x faster over wired networks and enjoy increased productivity when working with NAS devices with 2.5Gb/s Ethernet. Add an external monitor with up to 8K resolution via HDMI.
Beyond performance, with the Gemini Ultra's seven connectivity ports, you will experience an incredible level of versatility. Use your favorite accessories and charge small mobile devices via two USB-A 3.2 Gen 2 ports. Daisy chain up to five Thunderbolt devices so that you can create additional backups. Offload media cards faster and easier with the frontside UHS-II slot or external card readers via Thunderbolt or USB-C. Transfer files and work up to 2.5x faster over wired networks and enjoy increased productivity when working with NAS devices with 2.5Gb/s Ethernet. Add an external monitor with up to 8K resolution via HDMI.
Put Ultra X2 to Work
Make your dream of becoming an editing powerhouse a reality by utilizing the performance of NVMe SSDs. With dual drives preset in SoftRAID RAID 0, you'll have up to 1446 MB/s of bandwidth to handle demanding media workflows such as 8K video and 6K multi-cam sequences using advanced 10-bit and 12-bit codecs, high framerate footage, and ultra-high resolution raw pictures. Plus, you'll have all the advanced drive health monitoring benefits of SoftRAID so you can work worry free. You can also use SoftRAID to change to RAID 1 data protection with speeds up to 721 MB/s.
Ultra X2 Models
Pro photographers and photography studios on tight deadlines can batch edit and export thousands of 60MP raw pictures at blazingly fast speeds. Documentary filmmakers can easily ingest media and cut through hours of 4K footage at up to 1446 MB/s using RAID 0 with this all-in-one solution to keep all the files in one place. Professionals working in a studio with NAS devices can benefit from the faster speeds of the built-in storage as an active drive and backup their files back to the NAS at up to 2.5Gb/s when projects are completed.
Reclaim Your Desktop
With multi-drive media dumps, controllers, A/V outputs, and a mess of device cables, it can be hard enough to find space for your notebook let alone room to work. Cure your clutter woes by reclaiming your workspace with Gemini Ultra's centralized design. The latest technology advances in storage, ethernet speed, connection speeds, and display support deliver the professional results your work demands while neatly consolidating all your devices.
Stay Connected to Your Team and Media
Stay connected to your team and workflow faster with the Gemini Ultra's 2.5Gb Ethernet port. Great for shared workspaces and workflows, file transfers happen in a blink, so you have more creative work time. It's also great for sending your files over to a NAS to keep them safely archived.
Gain an 8K Perspective
Add the fresh, crisp perspective of an 8K display to your workflow with the Gemini Ultra's latest generation HDMI port. Whether in your home office or on a mobile studio job, seeing your work in full detail is just one connection away. Use it to free up your laptop port, so you can dock in and out quickly and stay mobile.
Ready to Work Anywhere
At 3.3 x 5.8 x 9.4" and weighing a little over 4 pounds with drives, the Gemini Ultra can travel wherever you need a compact yet super-fast storage and connectivity solution. It connects to Thunderbolt Macs and PCs and can work cross-platform using OWC MacDrive 11 Pro software (available separately).
Innergize Your Workflow with Highest Performance and Reliability
OWC Innergize is the first stage of the Capture to Completion ecosystem of OWC products designed to seamlessly propel professional photographers, videographers, and content creators to the highest level of workflow performance and reliability. This OWC custom-designed app is a complete health, performance, and field upgrade management tool when using OWC Atlas memory cards with OWC Atlas readers and reader equipped products.
Work with Maximum Confidence and Reliability
Health
Over time and use cycles, flash memory does wear out. Innergize verifies and reports the percentage of use life remaining. Now you can work with full confidence your OWC flash memory product will deliver the reliability you can trust.
Sanitize
Writes, deletes, and formatting all take their toll on memory cards. Innergize cleans and restores the flash memory performance of OWC memory cards so you can get the best results on every use.
Field Upgrade
When new cameras or firmware updates to existing cameras are introduced, they may not work properly with flash memory cards and drives. Innergize gives OWC memory card users the ability to quickly upgrade their firmware in the field for full compatibility, additional performance enhancements, and bug fixes for optimal reliability.
Over time and use cycles, flash memory does wear out. Innergize verifies and reports the percentage of use life remaining. Now you can work with full confidence your OWC flash memory product will deliver the reliability you can trust.
Sanitize
Writes, deletes, and formatting all take their toll on memory cards. Innergize cleans and restores the flash memory performance of OWC memory cards so you can get the best results on every use.
Field Upgrade
When new cameras or firmware updates to existing cameras are introduced, they may not work properly with flash memory cards and drives. Innergize gives OWC memory card users the ability to quickly upgrade their firmware in the field for full compatibility, additional performance enhancements, and bug fixes for optimal reliability.
Easy RAID Management
Harness the full capability of your NVMe array in Gemini Ultra with the easiest to use, broadest selection of RAID levels available. SoftRAID XT is a powerful and intuitive software RAID utility that guides your setup. It offers maximum volume capacity, optimum drive performance, data protection, or a combination of attributes. SoftRAID is ideal for anyone who needs to safely store and backup massive amounts of data, including video editors, audio producers, photographers, and graphic designers.
Professional Grade = Ready to Work
OWC understands having confidence in gear reliability is paramount to creative professionals. That's why every Gemini Ultra configured solution goes through an intensive performance certification prior to shipping. This ensures your Gemini Ultra arrives operating properly and immediately ready for demanding use.
UPC: 810149202261
In the Box
- OWC 16TB Gemini Ultra X2 Thunderbolt 3 RAID Array and Docking Station (2 x 7.68TB)
- Thunderbolt 3 Cable (2.4' / 0.7m)
- External Power Supply
- Power Cable
- SoftRAID XT License
- Limited 3-Year Manufacturer Warranty
Table of Contents
- Description
- Ultra-Performance and Convenience for Production Workflows
- Put Ultra X2 to Work
- Ultra X2 Models
- Reclaim Your Desktop
- Stay Connected to Your Team and Media
- Gain an 8K Perspective
- Ready to Work Anywhere
- Innergize Your Workflow with Highest Performance and Reliability
- Work with Maximum Confidence and Reliability
- Easy RAID Management
- Professional Grade = Ready to Work
OWC Gemini External HDD Specs
Key Specs
| Storage Capacity |
16 TB
|
| Included Drives |
2x 7.68 TB SSD
|
| Interface |
NVMe
|
| Number of Bays |
2x 2.5"/3.5"/M.2
|
| Inputs/Outputs |
2x USB-C Thunderbolt 3 (40 Gb/s)
2x USB-A 3.1/3.2 Gen 2 1x RJ45 2.5GbE 1x HDMI 2.1 |
| RAID |
RAID 0/1/JBOD
|
Drives
| Storage Capacity |
16 TB
|
| Included Drives |
2x 7.68 TB SSD
|
| Initial RAID Configuration |
RAID 0
|
| Interface |
NVMe
|
General
| Number of Bays |
2x 2.5"/3.5"/M.2
|
| Inputs/Outputs |
2x USB-C Thunderbolt 3 (40 Gb/s)
2x USB-A 3.1/3.2 Gen 2 1x RJ45 2.5GbE 1x HDMI 2.1 |
| Compatible Drive Interface |
SATA III, NVMe, U.2
|
| Media Card Slots |
SD/SDHC/SDXC
|
| Form Factor |
Desktop
|
| RAID |
RAID 0/1/JBOD
|
| Bridge Chipset |
Intel JHL7440
|
| Hot-Swap Support |
No
|
| Transfer Rates |
1446 MB/s (Read in RAID 0)
1350 MB/s (Write in RAID 0) 721 MB/s (Read in RAID 1) 678 MB/s (Write in RAID 1) |
| UASP Support |
No
|
Software
| OS Compatibility |
Linux
Windows 10 to 11 (64-Bit Only) Windows Server 2016 macOS 12 to 14 |
Security
| Encryption |
No
|
Electrical
| AC Input Power |
100 to 240 VAC, 50 / 60 Hz
|
| DC Input Power |
12 VDC at 10 A
|
| Power Source |
AC Adapter
|
Environmental
| Operating Temperature |
41 to 95°F / 5 to 35°C
|
| Operating Humidity |
8 to 90% ()
|
| Storage Temperature |
-4 to 140°F / -20 to 60°C
|
| Storage Humidity |
5 to 95% (Non-Condensing)
|
| Certifications |
RoHS, CE, FCC, VCCI, BSMI, RCM
|
Physical
| Color |
Black
|
| Status Monitoring |
LED Indicator
|
| Cooling |
1x 3000 rpm 60 mm Fan
|
| Noise Level |
19.3 dBA
|
| Material of Construction |
Aluminum
|
| Dimensions |
9.4 x 5.8 x 3.3" / 23.8 x 14.7 x 8.5 cm
|
| Weight |
3.5 lb / 1.6 kg
|
Packaging Info
| Package Weight |
6.665 lb
|
| Box Dimensions (LxWxH) |
13 x 11.2 x 4.8"
|
