Panasonic High-Speed Tracking Software Licens... Overview
Panasonic ET-SWR10G06V Software License is a 6-month license for the ET-SWR10 Real-Time Tracking Projection-Mapping Software Development Kit. Merging analog movement and digital content, ET-SWR10 expands creative possibilities for immersive sensory experiences, interactive exhibitions, and more.
Combined with a compatible projector, such as the Panasonic PT-RQ35K or PT-FRQ60 Series, this ready-to-use SDK (Software Development Kit) enables projection of animated content onto fast-moving objects at up to 240 frames per second with less than 5 ms input-to-projection latency. Image position updates continuously to match the object, tracking its motion smoothly with no apparent delay. More than a giant leap forward in display performance, the system is also easier to install, integrate, and operate.
Real-Time Tracking and Mapping
Merge moving objects with projected content. Combined with a compatible projector, this exclusive technology converts object marker location to projector XY coordinates. Image position syncs to marker position with less than 5 ms latency. From a dancer�s fluid motions to rapidly moving objects, tracking performance is utterly convincing.
The system does not require painstaking calibration associated with active-sensor systems�just install the SDK on your content server and connect a compatible IR emitter and camera to begin. Calibrate marker location with projector XY coordinates once, and projected content will remain in sync with almost any fast-moving object.
A real-time tracking projection-mapping system incorporating ET-SWR10 would comprise a compatible Panasonic laser projector, such as the PT-RQ35K or PT-FRQ60 Series, an IR emitter, an IR camera, and a PC content server with SDK installed. This PC connects all devices and can be configured as a monitoring terminal for the projectionist.
Performers can move freely and have content react to them instead of having to rehearse and memorize movements to match pre-produced content.
Public Participation with Interactive Content
Members of the public can participate in an installation, interacting with content without any preparation or knowledge of how the system works.
Choose an object to track. This can be an item covered in material that reflects infrared light or a special device that emits infrared light. Next, set the object in motion. Infrared light from an IR emitter (or from the IR-emitting object) is either reflected back or sent directly to a camera. Software installed on a content server receives data from the connected camera and uses it to determine the object's position. It converts this information into an XY location and sends it to the projector. The object's position is updated 240 times per second, allowing projected digital content to appear on and follow the object with unrivalled precision and with no apparent delay for extraordinarily clear and smooth reproduction performance.
Works with Short & Ultra-Short Throw Lenses
This flexible real-time tracking and projection-mapping system can be used in conjunction with Panasonic ultra-short throw and short throw lenses for compatible 3-Chip DLP laser projectors, including ET-D3LEW200 Short Throw Zoom Lens, ET-D3LEU100 Ultra-Short Throw Lens, and ET-D75LE95 Ultra-Short Throw Lens, in the context of a ceiling or floor-mounted short throw installation. IR emitter, IR camera, and projector can be installed separately with IR equipment located at screen center and projector mounted on the ceiling or floor very close to the screen, allowing projection designers to create highly immersive interactive exhibits in tight installation spaces where performers or viewers can approach close to the screen without casting a shadow.
In the Box
- Panasonic ET-SWR10 Real-Time Tracking Projection-Mapping Software License (6-Month)
Additional Resources
No additional resources available
Panasonic High-Speed Tracking Software Licens...Specs
General
| Compatibility |
Panasonic PT-FRQ60 / PT-FRQ50 / PT-RQ35K
|
