| ₹ 1090.43 includes GST and import duties. | |
| B2B customers can avail ₹ 166.29 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The 1827033 is a 8-position green pluggable PCB Terminal Block with tin-plated solder contacts, a polyamide insulator and the M2 screw connection. This MCVW 1,5/ 8-ST-3,81 terminal block has fully developed contact geometries and surfaces. It accepts 28 to 16AWG wire range.
- Generously dimensioned wiring space
- Plug-in direction vertical to the conductor axis
- Compact dimensions of the MCV 1,5 plug range
- 7mm Stripping length
- A1 Internal cylindrical gage
- UL94V-0 Flammability rating
Applications
Industrial
Product details
| Pitch Spacing: 3.81mm |
| No. of Positions: 8Ways |
| Wire Size (AWG): 28AWG to 16AWG |
| Conductor Area CSA: 1.5mm² |
| Wire Connection Method: Screw |
| Rated Current: 8A |
| Rated Voltage: 160V |
| Product Range: MCVW |
Other details
| Brand | PHOENIX CONTACT |
| Part Number | 1827033 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 1068.62 |
| 3-5 | ₹ 1057.72 |
| 5-10 | ₹ 1035.91 |
| 10+ | ₹ 1014.1 |
Bulk discount will be automatically applied during checkout based on quantity.
