| ₹ 1142.09 includes GST and import duties. | |
| B2B customers can avail ₹ 174.17 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The 1827046 is a 9-position green Printed-Circuit Board Connector with tin-plated contact surface and a polyamide insulator. The MCVW 1,5/ 9-ST-3,81 connector has screw connection with tension sleeve and the individual position coding by removing the coding tab and connecting the coding profile to the header.
- Generously dimensioned wiring space
- Plug-in direction vertical to the conductor axis
- M2 Screw thread
Applications
Industrial
Footnotes
In accordance with DIN EN 61984, COMBICON plug-in connectors have no switching power. During designated use, they must not be plugged in or disconnected when carrying voltage or under load.
Product details
| Pitch Spacing: 3.81mm |
| No. of Positions: 9Ways |
| Wire Size (AWG): 28AWG to 16AWG |
| Conductor Area CSA: 1.5mm² |
| Wire Connection Method: Screw |
| Rated Current: 8A |
| Rated Voltage: 160V |
| Product Range: MCVW1.5 |
Other details
| Brand | PHOENIX CONTACT |
| Part Number | 1827046 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 1119.25 |
| 3-5 | ₹ 1107.83 |
| 5-10 | ₹ 1084.99 |
| 10+ | ₹ 1062.14 |
Bulk discount will be automatically applied during checkout based on quantity.
