Description
PORTKEYS LH5P II Overview
- 1Description
- 2Camera Control Functions
- 3Tilta Motor Control
- 4Hi-Bright 5.5" Touchscreen Monitor
- 5DCI/UHD 4K Video
- 6Display Functions
- 7Sony L-Series Battery Plate
Add pro monitoring tools and control for select Canon cameras to your camera rig with the LH5P II 5.5" Touchscreen Monitor from PORTKEYS. This bright, 5.5" on-camera touchscreen display offers 2200 cd/m² brightness with the ability to input and output up to DCI 4K24 or UHD 4K30 video via HDMI. Compatible with Canon C100/200/300, R5/R6, and C70 cameras, this monitor features a built-in Bluetooth module that enables select camera functions and includes a control cable to connect your device to the monitor.
Camera Control Functions
- Camera control via the integrated Bluetooth module and control cable
- Control functions include iris, shutter, zoom, frame rate, and ISO
- Set shortcut key F to control camera recording start/stop
Tilta Motor Control
Provides wired control for Tilta Nucleus-N/M lens motors
Hi-Bright 5.5" Touchscreen Monitor
5.5" LCD on-camera monitor features 2200 cd/m² and a 1000:1 contrast ratio for daylight visibility
DCI/UHD 4K Video
Supports HDMI input and output up to DCI 4K24 or UHD 4K30
Display Functions
- 3D LUT support with custom LUTs via USB
- Customized peaking, false color, luma waveform
- Real-time eye focus
- Anamorphic de-squeeze
- Anamorphic lens calibration
- Frame guides, crosshairs, grids, crop
- Check field, zebra, luma histogram
- RGB waveform, audio meters
- HDR/HLG support
Sony L-Series Battery Plate
Power with the built-in L-Series battery plate or power your camera with a separately available dummy battery using the DC output
In the Box
- PORTKEYS LH5P II 5.5" Touchscreen Monitor with Camera Control for Canon C100/200/300/R5/R6/C70
- Control Cable for Canon C100/200/300/R5/R6/C70
- USB Flash Drive
- Power Cord
- 2 x 2.4 GHz Antenna
- Storage Box
Table of Contents
- Description
- Camera Control Functions
- Tilta Motor Control
- Hi-Bright 5.5" Touchscreen Monitor
- DCI/UHD 4K Video
- Display Functions
- Sony L-Series Battery Plate
PORTKEYS LH5P II Specs
Display
| Panel Type | LCD |
| Display Size | 5.5" / 14.0 cm |
| Resolution | 1920 x 1080 |
| Aspect Ratio | 16:9 |
| Viewing Angle | Horizontal: 178° Vertical: 178° |
| Touchscreen | Yes |
| Maximum Brightness | 2200 cd/m2 |
| Contrast Ratio | 1000:1 |
| Bit Depth / Color Support | 10-Bit (1.07 Billion Colors) |
| HDR Compatibility | Yes |
| Pixels Per Inch (ppi) | 401 ppi |
| Color Gamut | 100% Rec. 2020 85% DCI-P3 |
| Image Controls | Anamorphic De-Squeeze, Check Field, Color Temperature Selection, Customizable Aspect Ratios, False Color, Focus Assist, Focus Peaking, H/V Delay, Histogram, Image Flip, Screen Markers, Waveform, Zebra |
Inputs / Outputs
| Video I/O | 1 x HDMI Input 1 x HDMI Output |
| Embedded Audio | HDMI |
| Audio I/O | 1 x 1/8" / 3.5 mm Headphone Output |
| Built-In Speaker | None |
| Power I/O | 1 x Proprietary (24 VDC) Input/Output |
| Other I/O | 1 x Mini-USB 1 x USB-A Input |
| Media/Memory Card Slot | None |
| Wi-Fi | None |
Format Support
| Video Format | HDMI (8-Bit 4:4:4/4:2:2) DCI 4K: 24 UHD 4K: 30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080PsF: 30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 576p: 50 576i: 50 480p: 60/59.94/50 480i: 60/59.94/50 |
Power
| DC Input Power | 7 to 24 VDC |
| Battery Type | 1 x L-Series |
| Power Consumption | 13 W (Maximum) |
| Mounting | 1 x 1/4"-20 Female |
Environmental
| Certifications | FCC Part 15 C *as per Manufacturer |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
General
| Material of Construction | Aluminum, Glass |
| Dimensions | 5.7 x 3.5 x 1.22" / 144 x 90 x 30.88 mm |
| Weight | 10.1 oz / 285 g |
Packaging Info
| Package Weight | 1.17 lb |
| Box Dimensions (LxWxH) | 8.8 x 5.5 x 2.4" |
PORTKEYS LH5P II Reviews
Good match with Sony FX3
By David
Rated 5 out of 5
Date: 2022-09-08
Using Sony FX3 - wifi connecting is good; no drops can perform all camera functions wirelessly. Picture quality and features were exactly what I needed for video work, especially outside. Easy to see/use in bright sunlight.
