Description
PulseAudio PA66MK2 Overview
The PA66MK2 6x6 Audio Distribution Amplifier from PulseAudio equips you with an expandable audio distribution system with class D amplification to up to 18 zones. The unit features six 1 PA source inputs and six stereo/bridge mono outputs with onboard mode switches. An integrated 25W stereo audio amplifier enables you to drive two 4- to 8-ohm speakers. Daisy-chain up to three units together using the expansion port. Six IR emitter jacks and RS-232 connectivity help provide different communication options. Other options include iOS and Android app compatibility or a separately available keypad unit.
Features at a Glance
- 6 x 6 audio matrix with 6 bridgeable zones to accommodate 1 or 2 speakers per zone
- Provides a whole house audio control system�expandable up to 3 units for 18 zones of distributed audio
- RS-232-IP adapter and Android/iOS app allows for effortless control via smartphone or tablet
- Optional keypads with PoE and built-in IR receivers sold separately
- High-efficiency class-D amplification
- Stereo/Bridge mono adjustable outputs
- RS-232 port allows 2-way communication with third-party control systems
- Power output of 2 x 25W, 8 ohms per zone or 2 x 50W, 4 ohms per zone
- Power 115/230V adjustable
- Ext mute & system on 3.5mm mono mini phone jacks
- 6 IR emitter 3.5mm mono mini phone jacks + 1 IR emitter 3.5mm mono for all output jacks
- 1 PA input jack to set all zones to source 1
- 6 zone pre-amp outputs to connect external power amplifier
UPC: 741835116879
Items Included
- PulseAudio PA66MK2 6x6 Audio Distribution Amplifier
- RS-232 IP Adapter
- Expansion Ribbon Cable
- AC Power Cable
- Limited 2-Year Manufacturer Warranty
Additional Resources
PulseAudio PA66MK2 Specs
Input
| Audio Inputs |
6x 2RCA Female
|
Output
| Audio Outputs |
6x 2RCA Female Line
6x Block 6x 1/8" / 3.5 mm Female |
Audio Performance
| Input Sensitivity |
250 mV
|
| I/O Impedance |
Input:
47 Kilohms |
| Frequency Response |
20 Hz to 20 kHz
|
| SNR |
>85 dB
|
| THD+N |
0.1%
|
| Amplifier Power Rating |
8 Ohms:
25 W 4 Ohms: 50 W |
Hardware
| OS Compatibility |
Android/iOS
|
| Mobile App Compatible |
Yes: Android & iOS
|
| Wi-Fi |
No
|
| Bluetooth |
No
|
Power
| Power I/O |
1x IEC C13 Input
|
| Power Consumption |
Power Supply: 115 to 230 VAC
|
General
| Dimensions |
16.9 x 16.4 x 3.5" / 42.9 x 41.7 x 8.9 cm
|
| Weight |
25 lb / 11.3 kg
|
