Description
RCF F6-X Overview
- 1Description
- 2High-Quality Preamps
- 3EQ on Mono & Stereo Channels
- 424-Bit FX
The RCF F-6X is a sturdy, metal mixer designed for live sound applications. It has 2 mic/ine inputs and two stereo line inputs. Line connections can be made over 1/4" connections or RCA terminations.
You'll find 3-band EQs on the mono channels and 2-band EQs on the stereo line inputs. 48V phantom power is available on both microphone inputs. 24-bit effects are on hand to give you reverb, echo, delay, flanger, and more. Mixes can be routed to stereo XLR and 1/4" outputs as well as the stereo 1/4" headphone jack for monitoring.
High-Quality Preamps
High-quality preamplifiers with phantom power, inspired by the E-Series mixers, offer high-quality sound and dynamics. Line-level signals are less noisy when connected using the separate line-input jack sockets.
EQ on Mono & Stereo Channels
You'll find 3-band EQ on the mono channels, and 2-band EQ on stereo channels for transparent sound shaping.
24-Bit FX
RCF has selected 16 studio-quality effects designed for everyday use when you need great quality FX processing without the need of an external FX unit. You'll find Reverbs (halls, rooms, plates, spring), Delays (mono, stereo, and multi-tap), Chorus, Flanger, and Echo.
In the Box
- RCF F-6X 6-Channel Mixer with Multi-FX
- Power Supply
- Limited 3-Year Warranty
Table of Contents
- Description
- High-Quality Preamps
- EQ on Mono & Stereo Channels
- 24-Bit FX
RCF F6-X Specs
Inputs
| Input Connections | 2 x XLR Inputs 6 x 1/4" Inputs (2 x Stereo Pairs, 2 Mono) 4 x RCA Inputs (2 x Stereo Pairs) 1 x 1/4" Footswitch Input |
| Gain Range | 0 to -50 dB |
| Input Impedance | Mic: 14 Kilohms Line: 21 Kilohms Stereo Line: 15 Kilohms |
| Frequency Response | 20 Hz to 20 kHz |
| Gain Selection | 20 dB to -30 dB |
| Low Cut Filters | 80 Hz |
| Phantom Power | +48 V |
Outputs
| Output Connections | 2 x XLR Main Outputs 2 x 1/4" Main Outputs 1 x 1/4" Auxiliary Output 1 x 1/4" Headphones Output |
| Output Level | 28 dBu |
| Headphone Impedance | 150 Ohms |
System Specifications
| Equalization | Input Channels: 2 Shelving / 1 Generic High: ±15 dB at 10 kHz, Shelving Mid: ±15 dB at 1250 Hz, Bell Low: ±15 dB at 100 Hz, Shelving |
| Case Material | Metal |
| Frequency Response | 20 Hz to 20 kHz |
| THD+N | < 0.02% (20 dB Gain, 0 dBu Out, A-Weighted) |
| Power Requirements | 12 VDC, 2000 mA (Center Pin Positive) |
| Power Consumption | 12 W |
| External Power Supply (AC Adapter) | 100 to 240 VAC, 50/60 Hz |
| Dimensions (D x H x W) | 10 x 3.1 x 8.3" / 255 x 79 x 210 mm |
| Weight | 4 lb / 1.8 kg |
