Description
RF Venue COMBINE6HDR Overview
Get better wireless performance with the COMBINE6 HDR from RF Venue a high-dynamic-range antenna combiner developed for cross-brand flexibility for IEM (In-Ear Monitor) systems. The six-channel radio frequency (RF) combiner receives six incoming IEM transmitter RF signals and combines them to a single antenna output, helping to eliminate intermodulation issues caused by using multiple transmitter antennas.
The unit is housed in a half-rack chassis and features a coaxial line input and a pair of coaxial line outputs, allowing you to link a second COMBINE6 HDR (available separately) for a single rack space solution that can accommodate up to 12 IEM systems on a single antenna. Rack-mounting hardware and a 12V power supply is included.
Items Included
- RF Venue COMBINE6 HDR 6-Channel Antenna Combiner for In-Ear Monitors (470 to 608 MHz)
- Power Supply
- Set of Rack Ears (Long and Short)
- Half-Rack Connecting Plate with Mounting Hardware
- Limited 1-Year Manufacturer Warranty
Additional Resources
No additional resources available
RF Venue COMBINE6HDR Specs
| Inputs |
6 x Coaxial RF Inputs from Transmitters
|
| Output |
Coaxial RF Output to Antenna
|
| Mobile App Compatible |
No
|
| Power Source |
AC Adapter with Power Brick (Included)
|
| DC Input Power |
12 VDC at 3 A
|
| Power Consumption |
40 W
|
| Mounting |
1x Long Rack Ear
1x Short Rack Ear |
| Color |
Black
|
| Environmental Resistance |
No
|
| Package Weight |
6.975 lb
|
| Box Dimensions (LxWxH) |
19.4 x 12.7 x 3.5"
|
