Description
The DD11.0111.1111 is a non-illuminated IEC power Entry Module without line filter, UL94V-0 black thermoplastic housing. Appliance inlet protection class I according to IEC 61140, 1-pole fuse holder. 2-pole line switch and quick connect terminals (4.8 x 0.8mm). Screw-on version from front or rear side panel mount. Ideal for application with high transient loads.
- Ultra-compact design. Ideal for low profile designs
- IP40 Protection degree
- -25 to 85°C Operating temperature range
Applications
Power Management
Product details
| Gender | Receptacle |
| Current Rating | 10A |
| Product Range | DD11 Series |
| Contact Termination Type | Quick Connect |
| Voltage Rating | 250VAC |
| Connector Mounting | Panel Mount |
Other details
| Brand | SCHURTER |
| Part Number | DD11.0111.1111 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Application Note EN | |
