Description
Sky-Watcher Quattro Overview
- 1Description
- 2Optical Performance
- 3Focuser
- 4Mounting
Sky-Watcher's 10" f/3.94 Quattro Imaging Newtonian Telescope has been specifically engineered for astrophotography and astro-imaging performance. Its 1000mm focal length has been shortened to produce a fast f/3.94 focal ratio which helps to reduce the exposure times required for capturing detailed images of the Moon, planets, and deep-sky objects. To further help boost its performance are borosilicate mirrors which have a low coefficient of thermal expansion to reduce the effects of expansion/contraction due to temperature fluctuation. This helps limit distortion that can occur when moving the OTA from indoors to outdoors and limiting the scope's ability to resolve details. The entire optical system is fully multicoated to increase the reflectivity of all surfaces to produce brighter and sharper images.
For imaging and visual use, the ability to achieve tack-sharp focus is critical, so Sky-Watcher outfitted the Quattro with a large Crayford-style focuser. This design uses a steel rod held tightly against the focus tube under tension. Using this toothless friction system eliminates backlash and enables ultra-fine precision focusing. A large coarse-focus wheel quickly brings subjects into rough focus, and then the 10:1 fine-focus allows the user to precisely focus it without the risk of losing it as soon as the knob is released. Having the ability to use larger 2" accessories and eyepieces provides an immersive experience during observation sessions and the ability to use larger sensors for capturing images, and a reducer adapter is included if you want to use the more common 1.25" eyepieces.
The Quattro is offered here without a mount or tripod for users that have a solid observation platform. Its cradle ring assembly clamps over the OTA and allows the OTA to be positioned for balancing when mounted, the eyepiece to be precisely placed for more comfortable observations, and the entire rig to be adjusted to avoid interference with other equipment and accessories. A Vixen-style dovetail plate on the bottom of the cradle ring assembly makes this OTA compatible with any Vixen-style saddle.
- 10" / 254mm aperture
- 1000mm focal length
- f/3.94 focal ratio
- Optimized aperture-to-focal length (focal ratio) for enhanced astrophotography and imaging capabilities
- Highly reflective borosilicate mirrors
- Borosilicate mirrors have a low coefficients of thermal expansion to reduce the effects of expansion/contraction due to temperature fluctuations
- Highly reflective fully multicoated optics
- 8x50 straight-view finderscope
- Crayford-style design
- Accepts 2" eyepieces and accessories
- Reducer adapter allows the use of smaller, more common, 1.25" eyepieces
- Two coarse focus wheels, one on each side of eyepiece holder
- Fine smaller focus dial on right-side of eyepiece holder
- Crayford focusers use a toothless friction system that allows for super-fine precision focusing without backlash
- Cradle ring assembly enables the position and orientation of the scope to be adjusted for balance, ease of viewing, and to limit obstruction by other equipment
- Vixen-style dovetail plate
In the Box
- Sky-Watcher 10" f/3.94 Quattro Imaging Newtonian Telescope (OTA Only)
- 2-to-1.25" Reducer Adapter
- 8x50 Finderscope
- Limited 2-Year Warranty
- Description
- Optical Performance
- Focuser
- Mounting
Sky-Watcher Quattro Specs
| Optical Design | Newtonian Reflector |
| Aperture | 254 mm / 10" |
| Focal Length | 1000 mm |
| Focal Ratio | f/4 |
| Focuser | Dual-Speed Crayford |
| Eyepiece Barrel Diameter | 2" |
| Diagonal | None |
| Finderscope | Yes |
| Mounting | Vixen Style |
| Optical Tube Dimensions | 36.5 x 11.4" / 92.7 x 29 cm |
| Batteries | None |
| Adapter | None |
| GPS | No |
| Wi-Fi | No |
| Weight | 36.5 lb / 16.6 kg |
| Package Weight | 40 lb |
| Box Dimensions (LxWxH) | 40.5 x 19 x 18.5" |
Sky-Watcher Quattro Reviews
It's fantastic but cheaply built
I have been using this scope for 6 months and it's really nice but I had to change the focuser to make use of it. I would also recommend it if it were at its original price of $845 but it's shocking how much it has increased to. I'd rather save up and buy a better quality scope with that amount of money instead.
