Description
Solid State Logic THE BUS+ Overview
- 1Description
- 2Greatness Made Even Better
- 3Bus Compressor
- 4Dynamic EQ
By combining the infamous SSL Bus Compressor circuit design with 2-band parallel dynamic EQ and recall-friendly stepped controls, THE BUS+ from Solid State Logic ushers in both classic and innovative dynamics processing for anything from single tracks and stems to mixes and masters. Its top-of-the-line analog sonics and immense headroom scream "integrity" while the digitally controlled settings ensure precision, clean switching, and exemption from the unpredictability of traditional analog devices.
With four operating modes�Dual Mono, Mid-Side, Classic Stereo, and S/C Stereo, a stereo mode with a summed sidechain�and compression coloration options ranging from the gritty texture of the 4K console's "Hit Maker" to the transparency of the X Logic variant, THE BUS+ is an impressively versatile compressor. The addition of internal/external sidechains with a variable high-pass filter, a hidden transient expander, and a mix knob for variable parallel compression makes THE BUS+ a crown for any studio.
Greatness Made Even Better
THE BUS+ is designed to be SSL's supreme version of the SSL Bus Compressor, building on the original circuit with premium components (including 2181 THAT VCAs), sophisticated control, customizable harmonic saturation, advanced sidechaining, flexible routing, and unexpected processing tools such as dynamic EQ.
- Authentic, 100% analog circuit, controlled digitally using stepped front-panel pots
- Four modes of operation�Classic Stereo, Stereo (with summed sidechain), Dual Mono, or Mid-Side
- Huge +27.5 dBu headroom and selectable operating level (0, +10, or -5 dB)
- External sidechain inputs and sends
- Configurable processing order; put the Bus Compressor before or after the D-EQ
- Global bypass, clipping indicators, and manual/automatic sleep modes
Bus Compressor
This is the heralded SSL Bus Compressor of old, remade for today's production needs.
- LOW THD Mode reduces low-frequency distortion caused by compression
- F/B Mode alters the compression characteristics for a more "relaxed" style of compression
- 4K Mode's single-VCA operation with variable harmonic distortion brings grit and grunge
- Negative ratios allow for creative pumping effects and control of particularly loud signals
- New attack and release time constants including an additional auto setting
- Precision MDAC-controlled make-up gain in coarse (1 dB) or fine (0.5 dB) steps
- Variable sidechain high-pass filter control up to 300 Hz in 10 Hz steps
- Moving-coil gain reduction meters
Dynamic EQ
The D-EQ is SSL's powerful 2-band analog dynamic equalizer that lets you tweak the balance between background material and the main signal.
- Compress/expand modes with three choices of time constants for each band
- 16 selectable frequency points per band
- Adjustable range per band from 0.5 to 15 dB
- HF band can be switched to Bell shape, with selectable frequencies covering high-mids and highs
- Frequency band static make-up gain for LF and HF bands (in Stereo or Summed S/C Stereo) or LF band (in Dual Mono or Mid-Side)
- G-Series mode changes LF filter to be second order with degree of undershoot/overshoot
- Tricolor activity LEDs to indicate D-EQ activity
- Per-band bypass
UPC: 878076001500
In the Box
- Solid State Logic THE BUS+ 2-Channel Bus Compressor and Dynamic Equalizer
- IEC Power Cable
Table of Contents
- Description
- Greatness Made Even Better
- Bus Compressor
- Dynamic EQ
Solid State Logic THE BUS+ Specs
General
| Number of Channels | 2 |
| Inputs | 2 x XLR 3-Pin Female (Balanced) |
| Outputs | 2 x XLR 3-Pin Male (Balanced) |
| Sidechain | 2 x XLR 3-Pin Female Inputs 2 x XLR 3-Pin Male Sends |
Audio Performance
| Input Impedance | 10 Kilohms |
| Output Impedance | 60 Ohms |
| Maximum Input Level | 27.5 dBu at 1% THD |
| Maximum Output Level | 27.5 dBu at 1% THD |
| Compression Threshold | -20 to +20 dB |
| Compression Ratio | 1.3:1, 1.5:1, 2:1, 3:1, 4:1, 5:1, 10:1, 20:1, -2.5:1, -1.5:1, -0.5:1 |
| Attack Time | 0.1 to 40 ms |
| Release Time | 0.05 to 1.2 Sec, Auto, Auto 2 |
| Make-up Gain | Range: -10 to +20 dB Precision: <0.003 dB |
| Frequency Response | 20 Hz to 20 kHz (±0.025 dB, Bypassed) <1 Hz to >200 kHz (-3 dB Low and High Cut-Offs, Bypassed) 20 Hz to 20 kHz (±0.01 dB, Compressor In) <2 Hz to >180 kHz (-3 dB Low and High Cut-Offs, Compressor In) |
| THD + Noise | -95 dB / 0.0017% Typical (Bypassed, 1 kHz at 0 dBu) -106 dB / 0.0004% Typical (Bypassed, 1 kHz at +20 dBu) -88 dB / 0.004% Typical (Compressor In, 1 kHz at 0 dBu) |
| Noise | -95 dBu Typical (Bypassed) -90 dBu Typical (Compressor In) -89 dBu Typical (4K Mode In, Any Intensity) |
| Dynamic Range | 122.5 dB (Bypassed) 117.5 dB (Compressor In) |
| Crosstalk | < -118 dB (Bypassed, 20 Hz at +24 dBu) < -110 dB (Bypassed, 1 kHz at +24 dBu) < -90 dB (Bypassed, 10 kHz at +24 dBu) |
| Matching Tolerance | <0.05 dB (Bypassed) <0.02 dB (In, 1 kHz at 0 dBu) <0.1 dB (Dual Mono, Any Setting Gain Reduction <8 dB) |
Equalizer
| Bands | 2 |
| Frequency Response | 20 Hz to 20 kHz (±0.05 dB, LF In) <2 Hz to >200 kHz (-3 dB Low and High Cut-Offs, LF In) 20 Hz to 20 kHz (±0.05 dB, HF In) <2 Hz to >200 kHz (-3 dB Low and High Cut-Offs, HF In) |
| THD + Noise | -88 dB / 0.004% Typical (LF In, 40 Hz at 0 dBu) -81 dB / 0.008% Typical (HF In, 10 kHz at 0 dBu, 40 kHz Bandwidth) |
| Noise | -90 dBu Typical (LF In) -87 dBu Typical (HF In) |
| Headroom | >27 dB (LF and HF In) |
| Gain Accuracy | LF: ±0.05 dB Typical (LF In, 40 Hz at 0 dBu: -10 dB to +10 dB) HF: ±0.05 dB Typical (HF In, 10 kHz at 0 dBu: -10 dB to +10 dB) |
| Matching Tolerance | <0.05 dB (LF/HF In, 20 Hz to 20 kHz at 0 dBu) <0.1 dB (LF In, 40 Hz, Any Gain Change) <0.1 dB (HF In, 10 kHz, Any Gain Change) |
Power
| Power Supply | 100 to 240 VAC, 50/60 Hz (Auto-Ranging) |
| Power Consumption | 38 W (Operating) <1 W (Sleep) 10 W (Auto Sleep) |
Physical
| Rack Height | 2 RU |
| Dimensions (W x D x H) | 19 x 3.5 x 11.9" / 48 x 8.9 x 30.3 cm (Chassis Only) 19 x 3.5 x 12.9" / 48 x 8.9 x 32.8 cm (Including Front-Panel Controls) |
| Weight | 13.1 lb / 5.9 kg |
Packaging Info
| Package Weight | 19.03 lb |
| Box Dimensions (LxWxH) | 21.6 x 18.3 x 8.6" |
