Description
The BDX33C is a NPN complementary silicon power Darlington Transistor with built-in epitaxial planar technology. Designed for use in power linear and switching applications.
- Complement to BDX34C
- 0.25A Base current
Applications
Audio, Industrial
Product details
| Power Dissipation Pd | 70W |
| DC Collector Current | 10A |
| Collector Emitter Voltage V(br)ceo | 100V |
| Transition Frequency ft | - |
| Operating Temperature Max | 150°C |
| Transistor Polarity | NPN |
| DC Current Gain hFE | 750hFE |
| No. of Pins | 3Pins |
| Product Range | - |
| Automotive Qualification Standard | - |
| Transistor Case Style | TO-220 |
| MSL | - |
Other details
| Brand | STMICROELECTRONICS |
| Part Number | BDX33C |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
