Ultra-compact high-performance eCompass module suitable for use in tilt-compensated compasses, map rotation, position detection, motion-activated functions, free-fall detection, click/double-click recognition, pedometers, intelligent power saving for handheld devices, display orientation, gaming and virtual reality input devices.
- 3D digital linear acceleration sensor and a 3D digital magnetic sensor
- ±50 gauss magnetic dynamic range
- 16bit data output
- SPI/I2C serial interfaces
- Selectable power mode/resolution for accelerometer and magnetometer
- Single measurement mode for magnetometer
- Embedded self-test, Embedded temperature sensor, Embedded FIFO
- Programmable interrupt generators for freefall, motion detection and magnetic field detection
Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Other details
| Brand |
STMICROELECTRONICS |
| Part Number |
LSM303AGRTR |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
| Product Change Notice EN |
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
