₹ 7231.6 includes GST and import duties. | |
B2B customers can avail ₹ 1102.82 ITC on this product | |
100% Secure Payments | 100% Genuine product |
Description
The TEN 20-2423WIN is a 2-output board-mount isolated DC to DC Converter with tightly regulated output voltage and ultra wide 4:1 input voltage range. The TEN 20WIN series 20W converter features over voltage protection and output voltage trimming. This converter is ideal for applications which require isolated and tightly regulated voltages.
- Adjustable output voltage
- Short-circuit protection
- No minimum load required
- 1500VDC I/O Isolation
- Remote on/off
- Industry standard footprint
- Shielded metal case with insulated baseplate
- -40 to +85�C Extended operating temperature range
Applications
Power Management, Communications & Networking, Industrial
Product details
Output Power Max | 20W |
Input Voltage DC Min | 9V |
DC / DC Converter Mounting | Through Hole |
Output Voltage - Output 2 | -15V |
Output Current - Output 2 | 665mA |
Depth | 50.8mm |
Width | 25.4mm |
Product Range | TEN 20WIN Series |
DC / DC Converter Type | DIP |
Approvals & Standards | - |
Output Voltage - Output 3 | - |
Output Voltage - Output 1 | 15V |
Output Current - Output 3 | - |
No. of Outputs | 2 Output |
DC / DC Converter Output Type | Fixed |
Input Voltage DC Max | 36V |
Output Current - Output 1 | 665mA |
Height | 10.2mm |
Other details
Brand | TRACOPOWER |
Part Number | TEN 20-2423WIN |
Quantity | Each |
Technical Data Sheet EN | |
Miscellaneous EN | |
Application Note EN |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
Quantity | Price |
2 | ₹ 7086.97 |
3-5 | ₹ 7014.65 |
5-10 | ₹ 6870.02 |
10+ | ₹ 6725.39 |
Bulk discount will be automatically applied during checkout based on quantity.
