Description
The TEN 50-2412 is a 1-output board-mount isolated DC to DC Converter with tightly regulated output voltage and wide 2:1 input voltage range. The TEN 50 series 50W isolated high performance converter features very high reliability, overload protection and short-circuit protection. They do not need a minimum load and offer a high efficiency also at low load conditions. The output voltage is adjustable by external resistor. It is ideal for applications where space on the PCB is critical.
- Excellent efficiency up to 92%
- Remote on/off
- 1500VDC I/O Isolation
- -40 to +85�C Operating temperature range
Applications
Power Management, Communications & Networking, Industrial
Product details
| Output Power Max | 50W |
| Input Voltage DC Min | 18V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Depth | 50.8mm |
| Width | 25.4mm |
| Product Range | - |
| DC / DC Converter Type | DIP |
| Approvals & Standards | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 12V |
| Output Current - Output 3 | - |
| No. of Outputs | 1 Output |
| DC / DC Converter Output Type | Fixed, Adjustable |
| Input Voltage DC Max | 36V |
| Output Current - Output 1 | 4.16A |
| Height | 11mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TEN 50-2412 |
| Quantity | Each |
| Technical Data Sheet EN |  |
