Description
The VTX-214-006-105 is a 5VDC/6W PCB-mount 1-output AC to DC Power Supply features a small/compact size, encapsulated design, regulated, low standby power, fully isolated primary to secondary voltage, low ripple and noise (built-in filter network). Hiccup mode for over-power, overvoltage and short-circuit protection. This power supply output is fixed.
- 0.3W Maximum no load power
- >4200Vrms Fully Isolated primary to secondary
- >70% Efficiency
- UL94V-0 Flammability rating
- -25 to 70°C Operating temperature range
Applications
Power Management
Footnotes
L1 common mode choke.
Product details
| Power Supply Applications: ITE |
| No. of Outputs: 1 Output |
| Output Power Max: 6W |
| Output Voltage - Output 1: 5VDC |
| Output Current - Output 1: 1.2A |
| Output Voltage - Output 2: - |
| Output Current - Output 2: - |
| Output Voltage - Output 3: - |
| Output Current - Output 3: - |
| Power Supply Output Type: Fixed |
| Input Voltage VAC: 90V AC to 265V AC |
| Width: 30mm |
| Height: 24mm |
| Depth: 45.5mm |
| Product Range: - |
Other details
| Brand | VIGORTRONIX |
| Part Number | VTX-214-006-105 |
| Quantity | Each |
| Technical Data Sheet EN |  |
