YU0AS222M120D20C0H is a AS Type-Class X1/Y1 safety standard ceramic capacitor. Ideal for use as X/Y capacitors for AC line filters and primary-secondary coupling on switching power Supplies and AC adapters applications. Having internationally recognized safety certifications, This capacitor is well-suited for applications that require keeping potentially disruptive or damaging line transients and EMI out of susceptible equipment. It is also an ideal solution in situations where there is a need to suppress line disturbances at the power.
- Compact size
- Cost effective products
- Ideal for across the line applications
- Safety standard recognized for AC applications
- Coated with flame-retardant epoxy resin (equivalent to UL94V-0 standards)
- Operating temperature range -40°C to +125°C
- Dielectric strength: 4000VAC for 60 seconds
- 2200pF capacitance
- Insulation resistance 10000Mohm at 500VDC for 60 Seconds
Other details
| Brand |
WALSIN |
| Part Number |
YU0AS222M120D20C0H |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
